SkanRAD400

Did you know

SkanRad 400 needs a very low footprint to install with under table generator

Maintenance-free rail movements

Digital goniometer

Did you know

Today's Best Price (With Taxes)

With standard accessories and one year warranty

₹12,82,000

standard accessories

Sl no	Description	Qty
1	4 WAY FLOATING TABLE WITH 32KW Gen	1
2	COLUMN & RAIL ASSEMBLY	1
3	MONOBLOCK TUBE HEAD	1
4	X-RAY GRID	1
5	CHESTSTAND WITH BUCKY	1
6	LED COLLIMATOR	1

32 kW, 160 kHz High Frequency, Constant Potential
(DC), FPGA & Microcontroller based Generator
kV Range – 40 kV – 125 kV
mA Range – 10 mA – 400 mA (upto 630 mAs)
mAs Range – 0.32 mAs to 630 mAs
Exposure Time – 5 ms to 5 sec
Dual focus rotating anode (IEC60336) – 1.0/2.0 mm & 0.6/1.3 mm
Tube head heat capacity – 900 kJ
Anatomical Programming setting – user
Programmable 1250 Max with patient position indicator
Tube Head Rotation – ±120°
Tube head column Rotation – ±180°
10.4 inch Intuitive multifunction touch screen console on tube head
Input Voltage – 3 phase 400-415V AC, 50-60 Hz

Why SkanRAD 400 is best in the Industry?

Exclusive November Offer

Exclusive Offer

Want to know how SkanRAD 400 is unique?

Ergonomic Design and Easy workflow

Features an ergonomic design and simple workflows that help return the focus to your patients. Motorized hardware, minimal conduit/cables, tracking, and automation for faster examinations place less physical burden on your technicians.

Tube head mounted – 10.4” Touchscreen console

Parameter configuration, Technique selection Button, Digital Angle display and Intuitive patient positioning guidance are available on tube head LCD display.

Scalable DR configuration

Skanrad400 offers the versatility necessary to address a broad range of clinical applications in a cost-effective manner. Smooth operation, the latest generation CSI wireless/fixed detectors, and cutting-edge post-processing features help assure comprehensive performance.

Automated image stitching with sync movements

Multiple images in one fast, seamless, Synchronized automated exam on table and chest Bucky.

Attachable and detachable Grid

Removable grids in both the table and chest stand allow flexible working (such as Pediatrics).

Rotating Bucky

This provides flexible solutions, enabling exposure of areas other than the chest without taking out the panel and inserting it again in rotated direction or using larger panel.

See SkanRAD 400 in action

Talk to customer

What is the power of Skanrad 400?

32 kW

What is the power of Skanrad 400?

32 kW

What is the Maximum mA?

400mA

What is the Maximum mA?

400mA

What is the required kV?

125 kV

What is the required kV?

125 kV

What is the type of Anode?

Rotating Anode

What is the type of Anode?

Rotating Anode

What is the maximum patient weight on Table?

200 Kg

What is the maximum patient weight on Table?

200 Kg

What is the Detector size?

14″x17″ & 17″x17″ (wired / Wireless)

What is the Detector size?

14″x17″ & 17″x17″ (wired / Wireless)

Can it work on Dual detector mode?

Yes

Can it work on Dual detector mode?

Yes

What is input power requirement?

3 Phase 400-415 VAC, 50/60Hz

What is input power requirement?

3 Phase 400-415 VAC, 50/60Hz

What is the Anode Heat Content for SkanRAD400?

112 kHU

What is the Anode Heat Content for SkanRAD400?

112 kHU

What is the Minimum exposure time?

5ms

What is the Minimum exposure time?

5ms

Contact us for more

Fill out the form below with your requirements, and our team will get back to you with tailored solutions to meet your needs.
